Spectacle Flanges Class900
Spectacle Flanges Class 900 is one of spectacle flanges class style.
ASME b-16.48 2005 spectacles,spades&spacers
Specification:
| CLASS 900 | ||||||
| NOMINAL PIPE SIZE |
DIAMETER | OUTSIDE DIAMETER |
CENTRE LINE SPACING |
THICKNESS MIN |
WEB WIDTH |
|
| MM | INCH | ID | OD | A | T | B |
| 15 | 1/2 | 16 | 60 | 83 | 6.4 | 38 |
| 20 | 3/4 | 21 | 67 | 89 | 6.4 | 41 |
| 25 | 1 | 27 | 76 | 102 | 6.4 | 57 |
| 32 | 1 1/4 | 37 | 86 | 111 | 9.7 | 57 |
| 40 | 1 1/2 | 43 | 95 | 124 | 9.7 | 67 |
| 50 | 2 | 55 | 140 | 165 | 12.7 | 57 |
| 65 | 2 1/2 | 67 | 162 | 191 | 12.7 | 67 |
| 80 | 3 | 83 | 165 | 191 | 15.8 | 67 |
| 100 | 4 | 108 | 203 | 235 | 19.1 | 76 |
| 125 | 5 | 135 | 244 | 279 | 22.4 | 86 |
| 150 | 6 | 162 | 286 | 318 | 25.4 | 86 |
| 200 | 8 | 212 | 356 | 394 | 35.1 | 95 |
| 250 | 10 | 265 | 432 | 470 | 41.2 | 105 |
| 300 | 12 | 315 | 495 | 534 | 47.8 | 105 |
| 350 | 14 | 346 | 518 | 559 | 53.9 | 114 |
| 400 | 16 | 397 | 572 | 616 | 60.5 | 124 |
| 450 | 18 | 448 | 635 | 686 | 66.6 | 133 |
| 500 | 20 | 497 | 696 | 749 | 73.2 | 133 |
| 600 | 24 | 597 | 835 | 902 | 88.9 | 152 |
Flanges Catalog
*For more information about spectacle flanges class 900, please contact us.
