Monel K500 (UNS N05500) is an age-hardenable nickel-copper alloy performing well across a wide temperature range. It maintains low magnetic permeability and excellent non-magnetic properties, even at subzero temperatures. Compared to Monel 400, it offers similar corrosion resistance but boasts higher strength and hardness. Additionally, adding aluminum and titanium, followed by controlled heating, significantly boosts its properties.
Chemical Composition of Monel K500
| Élément | Ni | Cu | Al | Ti | Fe | Mn | Si | C | S |
|---|---|---|---|---|---|---|---|---|---|
| Content (%) | 63.0-70.0 | 27.0-33.0 | 2.3-3.15 | 0.35-0.85 | ≤2.0 | ≤1.5 | ≤0.5 | ≤0.25 | ≤0.01 |
Ce que nous faisons
Core Advantages of Monel K500
Monel K500 is precipitation hardened. It has excellent structural strength. This increases the reliability of the parts.
The alloy is easy to machine. It reduces production costs and saves time. In addition, the machining quality is higher.
Monel K500 can withstand dynamic loads. It extends equipment life. Customers get more consistent performance.
This material resists frictional wear. It reduces the frequency of equipment maintenance. As a result, the cost of use is lower.
Monel K500 has the same corrosion resistance as Monel 400. In addition, it is resistant to acidic atmospheres.
Mechanical Properties of Monel K500
| Biens | Tensile Strength (Rm) | Yield Strength (Rp0.2) | Elongation (A) | Hardness (HB) |
|---|---|---|---|---|
| Valeur | ≥1100 MPa | ≥790 MPa | ≥15% | ≥265 |
Applications of Monel K500
- Marine Service: Chains, cables, fasteners, and springs.
- Chemical Processing: Pump and valve components.
- Paper Production: Blades and scrapers for pulp processing.
- Oil and Gas: Drill tools, pump shafts, and impellers.
- Électronique: Sensors and other components.
Traitement thermique
Material Standards for Monel K500
- UNS No. N05500
- Werkstoff number: 2.4375
- ASTM Standard: B865
- DIN Standard: 17750, 17752, 17753, 17754
- ISO Standard: 6208
- BS Standard: 3072NA18, 3073NA18, 3075NA18, 3076NA18
- SAE AMS Standard: 4676
- NACE Standard: MR-01-75
Ce que nous faisons
Processing and Handling
Comparison with Other Materials
| Matériau | Major Components | Force | Résistance à la corrosion | Processability | Typical Applications |
|---|---|---|---|---|---|
| Monel K500 | Ni, Cu, Al, Ti | High | Talented | Good | Marine Equipments,Chemical parts |
| Monel 400 | Ni, Cu | Moyen | Talented | Easier | Marine and Chemical Equipments |
| Inconel 625 | Ni, Cr, Mo, V | * | Perfect | Harder | High Temperature,Aircraft Engines |
Future Outlook
